Crosby® McKissick 10" Snatch Block with Shackle - 5/8" to 3/4" Wire Rope

The Crosby® McKissick 10" Sheave Snatch Block with Shackle is built for high-load, fixed-position rigging. Designed for use with 5/8" to 3/4" wire rope, this block is part of the Type 419 series and features a forged steel swivel shackle for strong, secure anchoring. With an 8-ton working load limit and a 4:1 safety factor, it’s trusted in heavy industrial lifting and tensioning operations.

This snatch block includes bronze bushings for smooth sheave performance and reduced wear under load. The drop-side plate design allows fast rope setup in the field. While this model uses a shackle instead of a hook, it still benefits from the same modular system - compatible with hook assemblies from other 418/419 blocks ranging 4-1/2" to 14".

Heavy-Duty Snatch Block with Swivel Shackle for Secure Rigging

At 42 lbs, this snatch block provides serious strength while maintaining maneuverability in field use. It’s ideal for applications requiring permanent or semi-permanent rigging installations, directional pulling, and controlled lifting in crane, utility, or construction environments.

Key Features

• Wire Rope Compatibility: Fits 5/8" to 3/4" wire rope
• Sheave Diameter: 10" for smooth, efficient line control
• Load Rating: 8-ton working load limit
• Block Type: Crosby® McKissick Type 419 snatch block
• Shackle Assembly: Forged steel swivel shackle for stable attachment
• Interchangeable Compatibility: Works with hook assemblies from 418/419 blocks (4-1/2" to 14")
• Bronze Bushings: Low-friction, wear-resistant design for extended service life
• Product Weight: 42 lbs - strong, stable, and ready for the field
• Brand: Crosby® McKissick
• Manufacturer Part #: 109322
• Compliance: Meets or exceeds ASME B30.26 standards for lifting hardware
• Applications: Ideal for lifting, winching, load direction control, and permanent rigging points
