At 500 tons, this Compound Plus is the largest wireless tension load cell in Straightpoint's Plus line, built for the most demanding heavy-lift monitoring a crew will run. It's designed for use with Crosby shackles, though it's also compatible with other shackle brands, and runs on 6 AA alkaline batteries instead of a wired connection. The SW-HHP handheld reader is sold separately, the same as the rest of the Compound Plus line.

Key Features

• 500-ton tension load cell, hard-anodized aerospace-grade aluminum construction
• Broadcasts wirelessly to a Straightpoint SW-HHP handheld, covering up to 4 load cells at a time
• One-button tare, t/lbs/kg/kN unit selection, and an audible overload alarm
• Can log data through Straightpoint's INSIGHT software (sold separately)
• Enclosure meets IP67/NEMA 6 for electronics protection
• RFID tag, ASME B30.26 compliant, 2-year warranty coverage
• Ships complete with a calibration certificate, manual, and case
• A Crosby shackle pair is included with certain kit configurations
• Compatible with Crosby shackles as well as other shackle brands

Applications

• Tandem lifting and lowering, water bag load testing, and overhead weighing at the top of the line
• Bollard pull testing, tug testing, breakbulk applications, and heavy lift projects
• Offshore cranes, spreader beam load monitoring, vehicle towing load measurement, ship-to-ship transfers, and single point mooring
