8" x 16' Endless Twin-Path® High Performance Roundsling | Vertical Cap: 175,000 lbs.
8" x 16' Endless Twin-Path® High Performance Roundsling | Vertical Cap: 175,000 lbs.!
8" x 16' Endless Twin-Path® High Performance Roundsling | Vertical Cap: 175,000 lbs.
Specifications
Minimum bending radius: 1.4"
Tapered Body Width: 4"
At 8 inches, this endless HMPE sling is built for large-scale industrial rigging where capacity and low weight both matter. An endless twin path roundsling, this twin-path endless lifting sling and endless HMPE sling is stronger than a comparably sized wire rope or chain sling at only about 10% of the weight, easier for riggers to handle, and a good fit for fragile cargo since it's synthetic. This mid-range model carries a 175,000 lb. vertical capacity.
Key Features
- Built from two independent paths of K-Spec® core yarn under a protective outer jacket, giving backup protection since each path connects hook to load on its own
- Two layers of industrial-grade nylon make up the Covermax® jacket, with more than four times a polyester jacket's abrasion resistance
- Repairable if the jacket is damaged but the core yarns are unharmed
- Check-Fast® inspection system flags core yarn damage or overload at a glance
- Non-conductive, non-corrosive, water-resistant, UV-resistant, and load-conforming
- 1% elongation at rated capacity; load-tested to 200% of capacity
- Meets ASME B30.9 standards; temperature range -40°F (-40°C) to 180°F (82°C)
Applications
- General rigging jobs, such as machinery moves, that need solid capacity without the largest sizes in the line
- Low-headroom lifts where 1% elongation at rated capacity keeps the load from shifting
- Jobs needing a quick visual overload check between lifts via the Check-Fast® system
Complete Your Sling Setup
Finish your lifting setup with the right supporting hardware and protection. Add sling protection to help guard against abrasion, edges, and wear, and pair your sling with a properly rated wide body shackle such as the Crosby® G-2160 Bolt Type Wide Body Shackle or Van Beest Green Pin® P-6033 Wide Body Sling Shackle.
