M&W 0.55 Ton Straight Vertical Plate Clamp | 1.0 - 1.5 Jaw | 21717
M&W 0.55 Ton Straight Vertical Plate Clamp | 1.0 - 1.5 Jaw | 21717!
M&W 0.55 Ton Straight Vertical Plate Clamp | 1.0 - 1.5 Jaw | 21717
Specifications
ASME B30.BTH -1 Design Compliant
WLL (tons): 0.55
This M&W vertical plate clamp skips the minimum-load restriction other plate clamps carry, so material anywhere along its rated capacity gets a secure grip instead of only loads near the working load limit. A straight lug keeps the design simple, and a full 180-degree turning range still lets you flip a plate from vertical to horizontal or back in one motion.
Key Features
- Grips securely at any point along its rated capacity, not just near the working load limit
- Straight lug for a simple, low-profile attachment
- Flips plate a full 180 degrees between vertical and horizontal orientations
- Built from premium alloy in the United States, with no welded joints
- Jaw is self-locking and resets to the pre-load position automatically after each use
- Operates in temperatures from -40 to 170 degrees Fahrenheit
- Rated for surface hardness up to 400 Brinell (43 Rc)
- WLL and serial number clearly marked on the clamp
Applications
- Straightforward vertical plate lifting where a hinged lug's extra angle range isn't needed
- Any m&w vertical lifting clamp setup calling for a simpler, straight-lug design
- Vertical-to-horizontal plate turning in general fabrication work
