M&W 1.1 Ton Straight Vertical Plate Clamp | 1.5 - 2.25 Jaw | 21853
M&W 1.1 Ton Straight Vertical Plate Clamp | 1.5 - 2.25 Jaw | 21853!
M&W 1.1 Ton Straight Vertical Plate Clamp | 1.5 - 2.25 Jaw | 21853
Specifications
ASME B30.BTH -1 Design Compliant
WLL (tons): 1.1
This 1.1-ton M&W vertical plate clamp pairs a straight lug with a wider jaw range than the 0.55-ton straight-lug model, giving it more capacity for mid-weight plate work.
Key Features
- No minimum-load requirement across its rated range
- Straight lug at a step up in capacity from the 0.55-ton straight-lug model
- Full 180-degree vertical-to-horizontal turning
- Premium alloy, non-welded, made in the United States
- Jaw locks and self-resets to pre-load position after use
- -40 to 170 degrees Fahrenheit operating range
- Up to 400 Brinell (43 Rc) surface hardness
Applications
- Mid-weight plate handling calling for a simple, low-profile lug design
- Any m&w vertical lifting clamp setup that doesn't need the hinged lug's extra placement angle
- Facilities running multiple M&W capacity classes and standardizing on straight-lug hardware
