SKU: RP6HDG

Simpson Strong-Tie RP6HDG Retrofit Plate - Hot Dip Galvanized

Name: Simpson Strong-Tie RP6HDG Retrofit Plate - Hot Dip Galvanized
SKU: RP6HDG
Price: 42.99 USD
Availability: InStock

Finish

Gray Paint Hot Dip Galvanized

$42⁹⁹

Ships Nov 12 when you order now

Description

The Simpson Strong-Tie RP6HDG Retrofit Plate is engineered to reinforce masonry buildings by securely anchoring walls to roof or floor structures. Its 6" x 5 3/4" octagonal design meets the International Existing Building Code (IEBC) requirement of 30 square inches, ensuring compliance for both unreinforced masonry and multi-wythe solid brick walls. The hot-dip galvanized (HDG) finish provides enhanced corrosion resistance, making it suitable for exterior applications.

Features:

Code Compliance: Meets IEBC prescriptive requirements for unreinforced masonry and multi-wythe solid brick walls.
Aesthetic Design: Octagonal shape provides a visually appealing retrofit solution.
Versatile Rod Accommodation: Designed for use with a 3/4"-diameter rod; can also accommodate a 5/8"-diameter rod with an additional standard-cut washer under the nut.
Corrosion Resistance: Hot-dip galvanized finish ensures durability in various environmental conditions.

Specifications

Width: 6"

Length: 5-3/4"

Hole Diameter: 13/16"

Thickness: 3/8"

Material: Carbon Steel

Finish: Hot Dip Galvanized

Manufacturer Name: Simpson Strong-Tie

Quantity: 1

View Spec Sheet

Simpson Strong-Tie Limited Warranty

Reviews (0)

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Continue browsing

Holdowns and Tension Ties Reinforce Structural Connections

Holdowns and Tension ties are designed to strengthen critical structural connections where uplift and lateral forces occur. Commonly used in shear walls, deck connections, and wood framing, holdown anchors and tension ties help transfer loads from framing members to the foundation, reducing movement and improving overall structural stability.
Precision Fit for Critical Framing Connections

Tension ties and holdown connectors feature prepunched holes that allow accurate fastener placement and proper alignment during installation. These connectors reinforce high-load framing areas where standard fasteners alone may not provide sufficient strength.
Corrosion-Resistant for Outdoor Durability

Holdown anchors and deck tension ties are often installed in exterior environments where moisture and treated lumber are present. Many Simpson Strong- Tie connectors feature corrosion-resistant finishes like ZMAX or stainless steel to help maintain long-term strength and performance.
