SKU: PLB20K

Plate Lifting Beam - 20,000 Lb. Capacity

Regular price $5,97500

Description

Steel plate, sheet stock, and other tall, flat loads are awkward to sling safely, and a strap or chain alone can let the load shift or tip mid-lift. The M&W Plate Lifting Beam solves that with J-shaped hooks that grip the plate directly and hold it stable through the lift. Built with heavy-duty steel for job site and warehouse use, the lineup covers a capacity range of 10,000 to 20,000 lbs. so you can match the beam to the plate you're moving.

Key Features

  • J-hook plate grip: Purpose-built J-shaped hooks grip the edges of a plate or panel for a secure, stable hold during the lift.
  • 10,000 to 20,000 lbs. capacity range across the lineup, so you can size the beam to the load you're handling.
  • Heavy-duty steel construction built for repeated use handling steel, wood, and other flat, rigid materials.
  • High-visibility yellow powder coat finish that's easy to spot in a busy shop or yard and holds up to scratches and chipping.
  • Made in the USA and individually proof-loaded per OSHA requirements, with certification paperwork included.
  • Manufactured to meet ASME B30.20 and OSHA below-the-hook lifting device requirements.
  • 30-day limited manufacturer's warranty.

Applications

  • Lifting and repositioning steel plate in fabrication shops and steel yards.
  • Handling sheet stock, wood panels, and other tall, flat materials in a warehouse.
  • Job site material handling where flat loads need to stay stable and level during the move.

Specifications

Working Load Limit (lbs.): 20,000
Safety Factor: 3:1
Rated For Overhead Lifting: Yes
Throat Opening: 4"
Spread: 7'
Bail Dimensions: Inside Width: 5"
Inside Length: 9"
Diameter: 1.28"
End Fitting: Chain Sling Included
Material: Steel
Finish: High visibility yellow powder coated paint
Item Weight: 245 lbs.
Standards: Exceeds all ASME B30.20 and OSHA regulations.
Proof loaded per OSHA requirements.
Manufacturer Name: M&W
Manufacturer Part Number: 14632
Shipping and Returns: This item ships LTL; learn more. It ships complete with proof testing certificate and cannot be returned due to safety risks associated with used materials.
Additional Info: WLL (tons): 10
Headroom: 59"
Hook Width: 3.5"
Max Plate Width: 96"
