Simpson ECC78PC End Column Cap - Black Powder Coat

Simpson ECC78PC End Column Cap - Black Powder Coat

Regular price $205.09
Sale price $205.09 Regular price
0% off
Made to Order
Ships in 1-3 business days.


  • This item is made to order and is non-returnable- Please call us at 888-794-1590 for exact lead times on this product.

  • Simpson Strong-Tie ECC end column caps provide a high-capacity connection for column-beam combinations. This design requires the correct corresponding machine bolts to be installed for proper installation. This post base features a black powder coat finish for a high aesthetic and added corrosion resistance.

    NOTE: The correct fasteners installed in the correct position must be used to achieve published load values

    California Residents: WARNING


    Material: Carbon Steel
    Post Size: 8X
    Height: 8"
    Fasteners required: Beam - (2) 3/4" Machine Bolts; Post - (2) 3/4" Machine Bolts
    Thickness: 3 Gauge
    Quantity: 1
    Finish: Black Powder Coat
    Length: 10-1/2"
    Manufacturer name: Simpson Strong-Tie
    Beam size: 6-3/4"
    Additional information:
    Width (1): 6-7/8"
    Width (2): 7-1/2"
    Product Guide: View Spec Sheet


    •Certified welds for confidence in strength and loading
    •Uplift loads increased for earthquake or wind loading
    •Bolt spacing that meets NDS code requirements to ensure optimal performance
    •Diamond holes to provide temporary fastening


    •Use all specified fasteners; see General Notes
    •Bolt holes shall be a minimum of 1/32" to a maximum of 1/16" larger than the bolt diameter (per 2015 NDS, section; bolt holes should be drilled from one side all the way through the beam to maintain hole tolerances
    •Contact engineered wood manufacturers for connections that are not through the wide face
