Shop more GH Top Flange Girder Hanger
SKU: GHD46-8

Simpson GHD46-8 Top-Flange Girder Hanger

Simpson GHD46-8 Top-Flange Girder Hanger

Regular price $117.76
Sale price $117.76 Regular price
0% off
Ships in 1-3 business days.
Request Bulk Pricing
Fill out the form below or give our sales consultants a call at 888-794-1590.

Description:

  • This item is made to order and is non-returnable- Please call us at 888-794-1590 for exact lead times on this product.

The GHD is a girder-to-foundation wall connection. A mudsill on top of the GHD is required to achieve the table loads. Available in Hot Dip Galvanized, specify when ordering. For no saddle-style hangers or for skewed options, please see our non-saddle style GH Girder Top-Flange Hangers.

NOTE: The correct fasteners installed in the correct position must be used to achieve published load values

California Residents: WARNING

Specifications:


Fasteners required: (4) 0.162 x 3-1/2
Thickness: 12 Gauge
Width: 3-9/16"
Finish: Gray Paint
Length: 6
Girder size: 4x6
Product Guide: View Spec Sheet

Installation

• Insert four 0.162" x 3 1/2" nails into girder.
• H = girder height – mudsill thickness. Measurement is from the bottom of the top flange to the top of the seat.
• 1 1/2" clearance hole accommodates rebar or anchor. This is not required.

View full details
