SKU: LBSMB50036

Small Length Lifting Beam (Bale Top) - 500 Lb. Capacity - 3' Max Spread

Regular price $57900
Ships FREE in 5-7 business days.

Description

Short lifts in a tight warehouse aisle or a low-ceiling production area don't need a full-size spreader beam, they need something compact that still spreads the load evenly. The M&W Bale Top Small Length Lifting Beam is built for exactly that kind of short-reach lifting, with a bale top that connects straight to a crane hook and a compact frame that keeps headroom requirements to a minimum. The lineup covers a range of capacities and lengths, so there's a size to match most short lifts.

Key Features

  • Bale top attachment: Connects directly to a crane hook without needing a separate shackle at the top of the beam.
  • Compact, small-length frame designed to minimize the headroom needed above the load.
  • Offered across a range of capacities and lengths to fit different short-lift applications.
  • Heavy-duty steel construction built to hold up in demanding warehouse and manufacturing environments.
  • Custom hardware and configurations available for specialized lifting needs.
  • High-visibility powder coat finish that resists scratches, chips, and everyday wear.
  • Made in the USA and individually proof-loaded per OSHA requirements, with certification paperwork included.
  • Manufactured to meet ASME B30.20 and OSHA below-the-hook lifting device requirements.
  • 30-day limited manufacturer's warranty.

Applications

  • Short, even lifts in warehouses and distribution centers where headroom is limited.
  • Manufacturing floor material handling that calls for a compact, direct-to-hook lifting point.
  • Construction and fabrication settings where a full-length spreader beam isn't practical.

Specifications

Working Load Limit (lbs.): 500
Safety Factor: 3:1
Rated For Overhead Lifting: Yes
Spread: 3'
Shackle Size: 3/8”
Bail Dimensions: Inside Width: 2"
Inside Length: 4"
End Fitting: Bottom Shackles Included
Material: Steel
Finish: High visibility yellow powder coated paint
Item Weight: 21 lbs.
Standards: Exceeds all ASME B30.20 and OSHA regulations.
Proof loaded per OSHA requirements.
Manufacturer Name: M&W
Manufacturer Part Number: 20349
Shipping and Returns: This item ships complete with proof testing certificate; it cannot be returned due to safety risks associated with used materials.
Additional Info: WLL (tons): 0.25
Headroom: 6.8"
