Standard Adjustable Lifting Beam w/ Shackles - 15,000 Lb. Capacity - 6' to 12' Spread
Spread
Load Limit
Description
Description
Low-headroom lifts don't leave much margin for error, and this adjustable lifting beam is built to work in that tight space. The beam length adjusts to match the lift, and a shackle bottom design gives you flexible, secure attachment points for a range of lifting needs. Steel construction and a high-visibility safety yellow powder coat finish round out a beam meant for daily use on job sites, in warehouses, and in shops.
Key Features
- Adjustable length for matching the beam to the job instead of the job to the beam.
- Shackle bottom connections for secure, versatile attachment points.
- Made in the USA, with premium machined and welded construction.
- Individually proof-loaded to OSHA requirements, ships with certification paperwork.
- ASME B30.20 and OSHA compliant manufacturing.
- High-visibility safety yellow powder coat finish resistant to scratches, chips, and wear.
- Backed by a 30-day limited manufacturer's warranty.
Applications
- Confined-space and low-headroom lifts where a fixed-length beam won't fit
- Job sites and warehouses that handle a range of load sizes and need one adjustable lifting beam instead of several fixed ones
- General material handling and equipment lifts calling for secure shackle attachment points
- Shops and yards that need lifting beam flexibility for changing daily work
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects and other reproductive harm. For more information visit: www.P65Warnings.ca.gov.
Specifications
Specifications
Inside Length: 7"
Top Thickness: 2"
Thickness: 1"
Proof loaded per OSHA requirements.
Headroom: 23.7"
Bail Adjustment Length: 24"
Bail Adjustment Increments: 3"
Spread Increments: 3"
