SKU: CP-BLE-35-T

Straightpoint® 35 T Compound Plus - Bluetooth Enabled - CP35T

Straightpoint® 35 T Compound Plus - Bluetooth Enabled - CP35T!

1 4

Continue Browsing

Rigging Supplies & Rigging Hardware
SKU: CP-BLE-35-T

Straightpoint® 35 T Compound Plus - Bluetooth Enabled - CP35T

$7,681.79
Request Bulk Pricing
Request Bulk Pricing
Ships FREE in 14-21 business days.
Fill out the form below or give our sales consultants a call at 888-794-1590.

Load Cell:

Standard Load Cell Load Cell Kit with Shackles

Output:

Bluetooth Handheld

Fast Shipping

Shipping & Returns

Bulk Pricing Discounts

Business Solutions

Payment Options

American Express
Apple Pay
Discover
Google Pay
Mastercard
PayPal
Shop Pay
Venmo
Visa

Specifications

Safety Factor: 5:1
Load capacity: 77,000 lbs.
Pin Size: 2-1/4"
Type: Standard Load Cell
Output: Bluetooth
Power Source: 4 x AA Alkaline Batteries
Accuracy: +/- 0.1% of Full Scale
Resolution: 10 lbs.
Range: 328'
Data Rate: 3Hz - up to 200Hz can be ordered for dynamic load monitorning applications
Operating Temperature: -10° to +50°C | 14° to 122° F
Battery Life: 500 hours continuous
Display Type: 240x128 Multi-Line Dot Matrix with Backlight
Item Weight: 29 lbs.
Standards: IP67
Manufacturer Name: Crosby Straightpoint
Manufacturer Part Number: CP35T-BLE / 2789011
Description

The 35-ton Compound Plus continues Straightpoint's wireless tension load cell line into mid-range capacity, keeping the same hard-anodized, aerospace-grade aluminum build.

Key Features

  • 35-ton tension load cell, hard-anodized aerospace-grade aluminum construction
  • Sends readings wirelessly to a Straightpoint SW-HHP handheld, tracking up to 4 load cells at once
  • Handheld tare button, unit selection across t/lbs/kg/kN, and an audible alarm
  • Connects to Straightpoint's INSIGHT computer software (sold separately)
  • Internal enclosure rated to IP67/NEMA 6
  • RFID-tagged, meets ASME B30.26, 2-year warranty
  • Includes calibration and proof test paperwork, a manual, and a carrying case
  • Certain kit configurations include a pair of Crosby shackles

Applications

  • Tandem lifting and water bag load testing at mid-range capacity
  • Bollard pull, tug testing, and breakbulk applications
  • Spreader beam monitoring and vehicle towing load measurement
