Caldwell 1/2 Ton x 3' Lifting Beam | Dura-Lite 419-1/2-3
Spread
Load Limit
Description
Description
Steel lifting beams get heavy fast once capacity climbs, and that weight comes straight out of a crew's available lifting capacity and a rigger's energy on a long shift. This Caldwell Dura-Lite composite lifting beam is built from a fiber-reinforced polymer composite instead, trimming dead weight while holding up to repeated heavy use. It is also non-corrosive, which makes it a natural fit for marine and coastal work, and non-conductive, so it can be used on jobsites where sparking near electrical equipment is a real concern.
Key Features
- Fiber-reinforced polymer composite construction: Lighter than steel to rig and handle, without sacrificing durability.
- Non-corrosive and non-conductive: Built for marine environments and spark-sensitive jobsites alike.
- Steel-bushed lug holes: Attachment points resist wear over repeated use.
- UV-protective acrylic polyurethane finish for long-term outdoor durability.
- Rated for 2 million duty cycles at capacity when used as intended.
- Proof-tested to 200% of rated capacity, shipped with certification paperwork.
- Top link and bottom swivel latch hooks included.
- Industry-compliant: Conforms to ASME B30.9, BTH-1, and B30.20 requirements, design category B, service class 4.
- 2-year limited manufacturer's warranty.
Applications
- Warehouse and industrial lifting beam use where a single, fixed top pick point is all a lift requires.
- Marine, coastal, and outdoor rigging where corrosion resistance extends service life.
- Jobsites where a non-conductive beam is needed near live electrical work.
- Repetitive-duty lifting where crews want lighter beam weight without giving up rated capacity.
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects and other reproductive harm. For more information visit: www.P65Warnings.ca.gov.
Specifications
Specifications
Inside Length: 1.9"
Diameter: 0.38"
Headroom: 13.9"
