SKU: CLB1000-4

Caldwell 1/2 Ton x 4' Lifting Beam | Dura-Lite 419-1/2-4

Regular price $2,27500

Description

Steel lifting beams get heavy fast once capacity climbs, and that weight comes straight out of a crew's available lifting capacity and a rigger's energy on a long shift. This Caldwell Dura-Lite composite lifting beam is built from a fiber-reinforced polymer composite instead, trimming dead weight while holding up to repeated heavy use. It is also non-corrosive, which makes it a natural fit for marine and coastal work, and non-conductive, so it can be used on jobsites where sparking near electrical equipment is a real concern.

Key Features

  • Fiber-reinforced polymer composite construction: Lighter than steel to rig and handle, without sacrificing durability.
  • Non-corrosive and non-conductive: Built for marine environments and spark-sensitive jobsites alike.
  • Steel-bushed lug holes: Attachment points resist wear over repeated use.
  • UV-protective acrylic polyurethane finish for long-term outdoor durability.
  • Rated for 2 million duty cycles at capacity when used as intended.
  • Proof-tested to 200% of rated capacity, shipped with certification paperwork.
  • Top link and bottom swivel latch hooks included.
  • Industry-compliant: Conforms to ASME B30.9, BTH-1, and B30.20 requirements, design category B, service class 4.
  • 2-year limited manufacturer's warranty.

Applications

  • Warehouse and industrial lifting beam use where a single, fixed top pick point is all a lift requires.
  • Marine, coastal, and outdoor rigging where corrosion resistance extends service life.
  • Jobsites where a non-conductive beam is needed near live electrical work.
  • Repetitive-duty lifting where crews want lighter beam weight without giving up rated capacity.

Specifications

Working Load Limit (lbs.): 1,102
Safety Factor: 3:1
Rated For Overhead Lifting: Yes
Throat Opening: 0.89"
Spread: 4'
Bail Dimensions: Inside Width: 1.5"
Inside Length: 1.9"
Diameter: 0.38"
End Fitting: Bottom Swivel Latch Hooks & Top Link Included
Material: Fiber-Reinforced Polymer Composite
Finish: Acrylic Polyurethane
Item Weight: 14 lbs.
Standards: Complies with ASME B30.9, BTH-1, and B30.20, design category B, service class 4 regulations.
Manufacturer Name: Caldwell
Manufacturer Part Number: 419-1/2-4
Shipping and Returns: This item ships complete with proof testing certificate; it cannot be returned due to safety risks associated with used materials.
Additional Info: WLL (tons): 0.5
Headroom: 14.9"
