5" x 14' Endless Twin-Path® High Performance Roundsling | Vertical Cap: 50,000 lbs.
5" x 14' Endless Twin-Path® High Performance Roundsling | Vertical Cap: 50,000 lbs.!
5" x 14' Endless Twin-Path® High Performance Roundsling | Vertical Cap: 50,000 lbs.
Specifications
Minimum bending radius: .75"
Tapered Body Width: 2.5"
At 5 inches, this twin-path endless lifting sling moves into serious capacity while staying under a fraction of the weight of comparable wire rope. An endless twin path roundsling, this twin-path endless lifting sling and endless HMPE sling is stronger than a comparably sized wire rope or chain sling at only about 10% of the weight, easier for riggers to handle, and a good fit for fragile cargo since it's synthetic. This entry-level model carries a 50,000 lb. vertical capacity.
Key Features
- Twin-Path construction uses two independent paths of K-Spec® core yarn under a protective outer jacket, so each path acts as its own connection between hook and load
- The Covermax® jacket uses two layers of industrial-grade nylon, giving more than four times the abrasion resistance of a polyester jacket
- Repairable if the jacket is damaged but the core yarns are unharmed
- Check-Fast® inspection system flags core yarn damage or overload at a glance
- Non-conductive, non-corrosive, water-resistant, UV-resistant, and load-conforming
- 1% elongation at rated capacity; load-tested to 200% of capacity
- Meets ASME B30.9 standards; temperature range -40°F (-40°C) to 180°F (82°C)
Applications
- Lighter rigging jobs that still call for wire-rope-level capacity without the weight
- Crews new to the Twin-Path® line who want an entry point before sizing up
- Frequent repositioning jobs where an endless loop spreads out wear on the sling body
Complete Your Sling Setup
Finish your lifting setup with the right supporting hardware and protection. Add sling protection to help guard against abrasion, edges, and wear, and pair your sling with a properly rated wide body shackle such as the Crosby® G-2160 Bolt Type Wide Body Shackle or Van Beest Green Pin® P-6033 Wide Body Sling Shackle.
