SKU: SBCP10.75-HD-SLEEVE

M&W Sleeve for HD Spreader Beam Pipe End Caps

Regular price $4,72500
Ships in 1-3 business days.

Description

Long spreader beam builds sometimes need more pipe than a single length provides, and this sleeve is what joins two sections together. It's designed to work with the heavy-duty M&W spreader beam end cap kit, giving you a way to extend a custom-built spreader beam without sourcing a longer piece of pipe. Made in the USA and finished in safety yellow, it matches the rest of a build-your-own spreader beam setup.

Key Features

  • Made in the USA for quality you can verify.
  • Built to join two lengths of pipe for a custom, modular spreader beam build.
  • Compatible with the heavy-duty spreader beam end cap kit for 10.75" pipe.
  • Safety yellow finish for jobsite visibility that matches the rest of the spreader beam system.

Applications

  • Extending a custom spreader beam build beyond the length of a single piece of pipe
  • Modular spreader beam projects using the matching heavy-duty end cap kit
  • Shops and fabricators building their own spreader bar setups from stock pipe

Specifications

Safety Factor: 3:1
Rated For Overhead Lifting: Yes
Material: Steel
Finish: High visibility yellow powder coated paint
Item Weight: 185 lbs.
Standards: Exceeds all ASME B30.20 and OSHA regulations when assembled to specifications using AS53 Grade B Schedule 80 pipe.
Proof loaded per OSHA requirements.
Manufacturer Name: M&W
Manufacturer Part Number: 22524
Shipping and Returns: This item ships LTL; learn more. It ships complete with proof testing certificate and cannot be returned due to safety risks associated with used materials.
Additional Info: Minimum horizontal top rigging angle of 45°; M&W recommends a min of 60°
