SKU: BC80

Simpson BC80 8x Post Half Base - G90 Galvanized

Simpson BC80 8x Post Half Base - G90 Galvanized!

Skip to product information
1 of 4

Continue Browsing

BC/BCS Post Caps

$40.19

Request Bulk Pricing
Ships FREE today when you add 5 and order in the next 9 hours 50 minutes
Fill out the form below or give our sales consultants a call at 866-421-4854.

Specifications

Finish: G90 Galvanized
Length: 7-1/2"
Material: 18-Gauge Steel
Fasteners required: Post Flange - (6) 0.162 x 3-1/2" Nails Base Bottom - (4) 0.162 x 3-1/2" Nails
For Treated Lumber: No
Height: 4"
Manufacturer name: Simpson Strong-Tie
Post size: 8x
Thickness: 18 Gauge
Width: 7-1/2"
Description

The Simpson BC80 8x Post Half Base - G90 Galvanized enhances the strength and stability of your construction projects. These connectors are designed to facilitate the secure connection of beams to posts, ensuring robust and reliable support.

Crafted from durable 18-gauge steel, this post cap features flanges to provide both uplift and lateral resistance while it attains its full allowable load using either common nail or pneumatic nail sizes.

This product is intended for use with 8x posts but is also available in other sizes, including 4x, 4x6, 6x, and 8x for both nominal and rough-cut lumber.

Features:

  • Connection Type: Designed to connect a beam to a post and flanges provide both uplift and lateral resistance.
  • Lumber Size: Intended for use with a 8x post for light-duty connections.
  • Material and Finish: Made from 18-Gauge Steel for durability and finished with G90 Galvanized coating.
  • Allowable Load: Attains full allowable load using either common nail or pneumatic nail sizes.
