SKU: HUC66TF

Simpson Strong-Tie HUC66TF 6x6 Concealed Top Flange Face Mount Hanger - G90 Galvanized, Made to Order Non-Returnable

Simpson Strong-Tie HUC66TF 6x6 Concealed Top Flange Face Mount Hanger - G90 Galvanized, Made to Order Non-Returnable!

1 3

Continue Browsing

HUTF/HUCTF Top Flange Joist Hangers
SKU: HUC66TF

Simpson Strong-Tie HUC66TF 6x6 Concealed Top Flange Face Mount Hanger - G90 Galvanized, Made to Order Non-Returnable

$36.99
Request Bulk Pricing
Request Bulk Pricing
Made to Order
Ships today when you order in the next 10 hours 53 minutes
Fill out the form below or give our sales consultants a call at 888-794-1590.

Sizes:

Double 2" X 10" Double 2" X 12" Double 2" X 14" Double 2" X 6" Double 2" X 8" Triple 2" X 10" Triple 2" X 12" Triple 2" X 14" 3" X 10" 3" X 12" 3" X 6" 3" X 8" 3-1/8" X 12" 4" X 10" 4" X 12" 4" X 14" 4" X 16" 4" X 4" 4" X 6" 4" X 8" 5-1/8" X 12" 6" X 10" 6" X 12" 6" X 14" 6" X 16" 6" X 6" 6" X 8"

Fast Shipping

Shipping & Returns

Bulk Pricing Discounts

Business Solutions

Payment Options

American Express
Apple Pay
Discover
Google Pay
Mastercard
PayPal
Shop Pay
Venmo
Visa

Specifications

Width: 5-1/2"
Height: 5-3/8"
Thickness: 12 Gauge
Joist Size: 6" X 6"
For Treated Lumber: No
Material: Carbon Steel
Finish: G90 Galvanized
Manufacturer Name: Simpson Strong-Tie
Fasteners Required: Face - (10) 0.162" x 3-1/2" Nails Joist - (4) 0.162" x 3-1/2" Nails
Description

This item is made to order with varied lead times - Please call us at 888-794-1590 for exact lead times on this product

The HUCTF Heavy Top-Flange Hangers with Concealed Flanges provide a superior solution for securely attaching joists to beams or ledgers, particularly in end-of-wall and corner installations. Engineered for strength and durability, these connectors ensure even load distribution, enhancing the structural integrity of your projects.

Key Features:

  • Concealed Flange Design: Ideal for applications where a clean, seamless aesthetic is required, such as end-of-wall or corner placements.
  • Heavy-Duty Construction: Made from 12-gauge steel for robust support and longevity.
  • G90 Galvanized Finish: Provides excellent corrosion resistance, making it suitable for interior and exterior applications.

Applications:

  • Residential and Commercial Use: Suitable for a variety of structural projects, including floors, ceilings, and roofs.
  • End-of-Wall Installations: Designed for joists terminating at the end of a wall while maintaining a strong, concealed connection.
  • Corner Joist Connections: Ensures structural stability in corner placements while offering a clean look.

Installation:

  • Fastening Requirements: Use all specified fasteners according to manufacturer guidelines for secure attachment.
  • Compatible Header Size: Minimum recommended header or ledger size is 3 1/2 inches.
  • No Modifications: These hangers cannot be modified for sloped or skewed seat applications.

NOTE: The correct fasteners installed in the correct position must be used to achieve published load values
